Lamp body
ADC12 high-strength die-casting aluminum lamp body, the surface is sprayed with outdoor sand grain weather-resistant imported powder
lens
PMMA optical lens, light transmittance up to 90%
Transparent material
Ultra-white 8mm tempered glass
Sealed structure
Structure waterproof or non-vulcanized colloid potting waterproof
Light Engine
Original brand imported light source, optional Osram, Cree, Philips, etc.
Ambient temperature
-20℃~45℃
Frame
High-strength special aluminum
Electric wire
Corrosion resistant rubber wire 2X1mm², 3X1mm², 2X1+3X0.5mm²
Work style
Switch is always on, DMX512, Triac, PWM, 1-10V
Contact us
deep hidden design of the light source to minimize glare interference
professional light distribution scheme design, ultra-white high-transmittance tempered glass
the lamp body is made of ADC12 high-strength die-cast aluminum, 316L stainless steel face ring with extremely high corrosion resistance, and high-strength installation embedded parts are provided
The American tiger powder baking paint spraying process is used to effectively improve the performance of acid and alkali resistance
Integrated heat dissipation design can balance the life of the lamp in a complex environment
| Model | Product Category | Working Voltage | Product Power | Color Temperature | Luminous Angle | Number of Light Sources | Control Method | Lamp Body Material | Lamp Shade Material | Protection Level |
| YH-D111413 | Underground light | DC24V AC220V | 12W 18W 24W | 3000K 4000K RGB RGBW | 8°/15°/30° 40°/60° | 6pcs | The switch is always on, external control DMX512 | ADC12 die-cast aluminum | Ultra-white tempered glass | IP67 |
