Lamp body
ADC12 high-strength die-cast aluminum lamp body, the surface is sprayed with outdoor special sand grain weather-resistant imported powder
lens
PMMA optical lens, light transmittance up to 90%
Transparent material
Ultra-white 4mm tempered glass
Sealed structure
Structure waterproof or non-vulcanized colloid potting waterproof
Light Engine
Original brand imported light source, optional OSRAM, Cree, Philips, Seoul, etc.
Ambient temperature
-20℃~45℃
Frame
High-strength special aluminum
Electric wire
Corrosion resistant rubber wire 2X1mm², 3X1mm², 2X1+3X0.5mm²
Work style
Switch is always on, DMX512, Triac, PWM, 1-10V
Contact us
traditional classic exterior design, which can be integrated with a variety of buildings
professional structural waterproof design, excellent outdoor protection performance
professional light distribution scheme design, ultra-white high-transmittance tempered glass
The lamp body is made of high-quality ADC12 die-cast aluminum, which efficiently improves the heat dissipation performance
the surface is treated with a corrosion-resistant outdoor special spraying process
| Model | Product Category | Working Voltage | Product Power | Color Temperature | Luminous Angle | Number of Light Sources | Control Method | Lamp Body Material | Lamp Shade Material | Protection Level |
| YH-T111020A | Flood light | DC24V AC220V | 36W | 3000K 4000K RGB RGBW | 15°/20°/30° 40°/60° | 12pcs | The switch is always on, external control DMX512 | ADC12 die-cast aluminum | Ultra-white tempered glass | IP66 |
| YH-T111020B | 36W | 24°/36°/60° | 1pcs |
