Lamp body
All-metal 6063 high-quality aviation aluminum extrusion, surface anodizing treatment or spraying outdoor special sand grain weather resistant powder
Transparent material
Anti-ultraviolet anti-yellowing milky white PC cover
Sealed structure
Small molecule polyurethane high-density colloidal waterproofing
Light Engine
Original brand imported light source, optional OSRAM, Cree, Philips, Seoul, etc.
Ambient temperature
-20°C~45°C
Frame
Aluminum bracket or embedded buckle
Electric wire
Corrosion resistant rubber wire 2X1mm², 2X1+3X0.5mm²
Work style
Switch is always on, DMX512, Triac, PWM, 1-10V
a minimalist appearance design adapted to modern aesthetics, perfectly integrated with a variety of buildings
Lightweight design and keep firm, classic hidden thread and back-out thread
patented light diffusion design, providing soft light
The whole lamp is made of high-quality 6063 aviation aluminum, which efficiently improves the heat dissipation performance
stainless steel buckle bracket, side screw fastening bracket
Model | Product Category | Working Voltage | Product Power | Color Temperature | Luminous Angle | Number of Light Sources | Control Method | Lamp Body Material | Lamp Shade Material | Protection Level |
YH-L322121 | Linear lights | DC24V | 10W 12W | 3000K 4000K RGB RGBW | 120° | 48 | The switch is always on, external control DMX512 | 6063 Aviation Aluminum | UV-resistant transparent PC cover | IP65 |
