Lamp body material
One-piece molding process, high protection level, using thickened high-quality flame-retardant transparent blended modified engineering plastics
Beam angle
Large light-emitting angle, conducive to viewing from multiple angles
Safety level
Flame-retardant grade V-0, class Ⅲ
Sealed structure
Non-vulcanized colloid potting and waterproofing, achieving IP68 waterproof level
Light Engine
Original brand imported light source, optional OSRAM, Cree, Philips, etc.
Ambient temperature
-20℃~45℃
Installation method
Aluminum card slot/steel buckle/hole installation/screw fixation
power line
Weather resistant wire 2X1mm², 2X0.75+3X0.5mm²
Way of working
The switch is always on, DMX512
Contact us
Professional and stable performance, suitable for various engineering projects
One-piece molding design, secondary packaging process, high-performance waterproof, up to IP68 level
High-quality flame-retardant co-plastic lamp body, UV resistant, yellowing resistant and waterproof potting glue
Excellent heat dissipation performance, can achieve a long service life of the lamp
Using ultra-high-brightness full-color light source, a large angle supports a larger viewing angle
| Model | Product Category | Working Voltage | Product Power | Color Temperature | Luminous Angle | Number of Light Sources | Control Method | Lamp Body Material | Lamp Shade Material | Protection Level |
| YH-G440803 | Point light source | DC24V | 1.44W | 3000K 4000K RGB | 120° | 8 | The switch is always on, external control DMX512 | Imported flame-retardant co-plastics | Imported high permeability plastic | IP68 |
