Lamp body
ADC12 high-strength die-casting aluminum lamp body, the surface is sprayed with outdoor sand grain weather-resistant imported powder
lens
PMMA optical lens, light transmittance up to 90%
Transparent material
Ultra-white 4mm tempered glass
Sealed structure
Waterproof structure or water-proof vulcanized gel potting
Light Engine
Original brand imported light source, optional OSRAM, Cree, Philips, and others
Ambient temperature
-20℃~45℃
Frame
Special aluminum for high strength
Electric wire
Corrosion resistant rubber wire 2X1mm², 3X1mm², 2X1+3X0.5mm²
Work style
Switch is always on, DMX512, Triac, PWM, 1-10V
Contact us
a minimalist matrix appearance adapted to modern aesthetics, perfectly integrated with a variety of buildings
professional structural waterproof design, excellent outdoor protection performance
professional light distribution scheme design, ultra-white high-transmittance tempered glass
The lamp body is made of high-quality ADC12 die-cast aluminum, which efficiently improves the heat dissipation performance
the surface is treated with a corrosion-resistant outdoor special spraying process
| 型号 | 产品类别 | 工作电压 | 产品功率 | 色温 | 发光角度 | 光源数量 | 控制方式 | 灯体材质 | 灯罩材质 | 防护等级 |
| YH-T601111 | 投光灯 | DC24V AC220V | 24W 36W | 3000K 4000K RGB RGBW | 3° 10° 15° 30° 60° | 12 | 开关常亮 外控DMX512 | ADC12 压铸铝 | 超白钢化玻璃 | IP66 |
